5 gallon 24 cavities cap mold
SH has very rich experiences in making multi cavity 5 gallon cap mould, we could make 8 cavities 5 gallon cap mould, 16 cavities 5 gallon cap mould, 24 cavities 5gallon cap mould, 32 cavities 5 gallon cap mould etc.
5 gallon cap material: LDPE
Mould core and cavity steel: S136 from Stavax Hardness: HRC45-52
Mould life: 1M shots
Mould spare parts: Shuanghao standard mould base
Mould base: Measure up to D-M-E metric standard or SINO standard
Cycle time: 18s+/-2s
Hot runner system: 24 tips pin point gate from ANOLE brand
